Equipment

2018 HAAS VF2 Mill

• SPECIFICATIONS
• Longitudinal Travel (X-Axis): 30"
• Vertical Travel (Y-Axis): 16"
• Spindle Travel (Z-Axis): 20"
• Spindle Speeds: 8100 RPM Max
• Spindle Horsepower: 30 HP
• Spindle Taper: #40 CAT
• 4th Axis Option: HRC-210 Rotary

2019 HAAS UMC 750

• SPECIFICATIONS
• Longitudinal Travel (X-Axis): 30"
• Vertical Travel (Y-Axis): 20"
• Spindle Travel (Z-Axis): 20"
• Spindle Speeds: 8100 RPM Max
• Spindle Horsepower: 30 HP
• Spindle Taper: #40 CAT
• A Axis Travel: 360 deg
• B Axis Travel (Trunnion): -35 to 110 deg

Mazak Integrex 30Y CNC Lathe With Live Tooling

• SPECIFICATIONS
• Chuck Size: 12" Hydraulic Chuck
• Travel X: 17.75"
• Travel Y-Axis: +/- 3.5"
• Travel Z-Axis: 40.5"
• Spindle Speeds: 35-3,500 RPM
• Spindle HP: 30 HP
• Rotary Tool Spindle Taper: #40
• Rotary Tool Spindle Speed: 15-6000 RPM
• Rotary Tool Spindle HP: 10 HP

2021 Doosan Lynx 2100M

• SPECIFICATIONS
• Chuck Size: 6" Hydraulic Chuck
• Travel X: 13.78"
• Travel Z-Axis: 13.00"
• Spindle Speed: 6,000 RPM
• Spindle HP: 20 HP
• Rotary Tool Spindle Speed: 6000 RPM
• Rotary Tool Spindle HP: 5 HP

Mitutoyo Crysta-Plus M 443 CMM

• SPECIFICATIONS
• Travel X-Axis: 16.00"
• Travel Y-Axis: 16.00"
• Travel Z-Axis: 12.00"

Mitutoyo PH-A14 Optical Comparator

• SPECIFICATIONS
• Screen Size: 14"
• Max Work Load: 100 Pounds
• Magnification Lens: 10x
